Monocular thermal imaging rangefinder night vision device
-
Model
- SSK/NW-SYNC55
- SSK/NW-SYNC55X
Current model: SSK/NW-SYNC55/55X
Retail price
¥ 9999
Market price
¥ 9999
The SSK/NW-SYNC55 and SYNC55X are equipped with a 12-μm vanadium oxide detector, delivering high sensitivity and high‑resolution thermal imaging to capture the temperature distribution and contours of targets. They feature a high‑resolution (1024×768) OLED display that renders vivid colors and contrast, enhancing viewing comfort and accuracy.
Remaining inventory
19998
隐藏域元素占位
Multiple ways of use
Multiple Operation Modes
Aim-down-sights mode
Weapon aiming mode enables rapid target acquisition and supports precision shooting in conditions where visible light cannot penetrate, such as complete darkness, smoke, rain, or snow. It is widely used in military and law enforcement tactics, hunting, and other scenarios.
Handheld mode
Flexible and portable, with a low learning curve, it is suitable for large‑scale mobile searches, ad hoc observations, rapid inspections, and other scenarios.
Combat and Observation Capabilities
Combat and observation capability
One-click gun calibration
With its intelligent calibration feature—triggered by a single button, automatically calculating offsets, and rapidly correcting reticle alignment—the traditional gun‑zeroing process is greatly simplified, enabling “one shot to zero, quick reset.”
Crosshair reticle
The distinctive crosshair reticle pattern is essential for rapid target acquisition and precision at any range, and it supports multiple color options.
Impact footage
Equipped with a highly sensitive built-in vibration sensor, it automatically starts recording upon detecting impacts or other sudden events, and supports pre-recording to capture and save video segments both before and after the impact.
Expansion and Connection
Expansion and Connection
Wireless transmission
Wi‑Fi/hotspot; supports viewing and live streaming via mobile apps on smartphones, tablets, and laptops.
Product Overview
Overview
A high-performance infrared thermal imaging night vision device that integrates multi-mode observation and wireless transmission.
Multiple functions: handheld/aiming‑on‑gun
Built-in 35mm professional infrared lens
Compact overall, convenient for individual soldiers to carry.
Functions and Capabilities
Capabilities
Display Mode
OLED high-definition display, supporting nine color modes, including white-hot, black-hot, brown, iron-red, and rainbow, among others.
Laser rangefinding
Night-vision monocular thermal imaging sight equipped with a high-precision, eye-safe laser rangefinder, offering one‑button ranging accuracy of ±1 meter.
Electronic Zoom Picture-in-Picture Mode
Supports continuous 1–8x electronic picture-in-picture zoom, preserving the field of view, enabling real-time monitoring, and enhancing target recognition accuracy.
Pitch angle + Roll angle
Dual-parameter monitoring of pitch and roll angles enables real-time, full‑attitude data feedback from the night vision device, accurately reporting the observed field of view’s elevation, depression, or lateral tilt and roll states.
Technical Specifications
Technical parameters
Core Specifications
Monocular Multifunctional Thermal Imaging Night Vision System | ||
Model number | SSK/NW-SYNC55 | SSK/NW-SYNC55X |
Thermal imaging parameters | ||
Detector Type | Uncooled vanadium oxide | |
Operating band | 8 ~ 14 mu m | |
Probe Specifications | 384 × 288 ( 12 mu m ) | 640×512 (12 μm) |
Field of view angle | 5.3 °× 4. ° (384 Resolution ) | 8.8°×7.0° (640 resolution) |
Polarity | Black fever / White-hot | |
Image frame rate | 50Hz | |
Image denoising | Digital filtering | |
Lens parameters | 54mm@ F=1.0 | |
Focusing method | Manual | |
Electronic amplification | 1 ~ 8 Continuous amplification by a factor of two | |
Zoom mode | Standard zoom / Picture-in-picture zoom | |
Hotspot Tracking | Support | |
Image enhancement | Support | |
Pseudo-color mode | Support white-hot / Black fever / Brown / Iron Red / Rainbows, etc. 9 Color mode | |
Division lines and colors | 3 Types of division lines, 5 Color of the division line for planting | |
Detection range | 2000 rice ( Typical climatic conditions) | |
Recognition distance | 500 rice ( Typical climatic conditions) | |
Eyepiece parameters | ||
Display screen | 0.39 inch OLED ( 1024 × 768 ) | |
Contrast | 1000:1 | |
Eye relief | 25 ~ 70mm | |
Eyepiece magnification | 15 times | |
Image parameters | ||
Video and photo playback | Supports one-tap photo and video capture, as well as local playback. | |
Image output | HDMI@1024 × 768 | |
Storage capacity | Standard configuration 64G( Optional 256G) | |
Interface Description | ||
Video output | HDMI | |
Wireless transmission | WIFI / Hotspot, compatible with mobile devices such as smartphones, tablets, and laptops. APP Watch and Live Stream | |
Ranging distance |
| 1200 meters (accuracy ±1 m) |
Ranging wavelength |
| Pulse 905 nm |
Data sensor | ||
Impact footage | Impact-triggered automatic recording; pre‑recording saves video before and after the impact; adjustable impact video duration and sensitivity. . | |
One-click gun calibration | AI Intelligent hotspot recognition and correction of the dividing line to a specified position. | |
Azimuth sensor | Static accuracy 0.05 °Dynamic 0.1 ° | |
Accelerometer | 2G ~ 60G Internally adjustable | |
Roll angle sensor | Range ± 90 °Static accuracy 0.05 °Dynamic 0.1 ° | |
Pitch angle sensor | Range ± 90 °Static accuracy 0.05 °Dynamic 0.1 ° | |
Physical parameters | ||
Impact strength | 1000G | |
Waterproof seal | IP66 (Airtight) | |
Operating ambient temperature | -40 °C～ +60 °C | |
Storage temperature | -45 °C～ +70 °C | |
Operating humidity | Humidity less than 90%( No condensation ) | |
Typical power consumption | ≤ 2.3W | |
Battery capacity | 16340 Rechargeable lithium battery 3.7V @ 2600mAH | |
Working hours | Continuous working hours >5 hour | |
Product dimensions | 168×69×61 (mm) 168×99×61 (mm) | |
Product weight | ≤631 g (without battery) ≤667 g (with battery); ≤695 g (without battery) ≤731 g (with battery) | |
Equipped with accessories | ||
Charging data cable | USB Turn TAPE-C | |
Charger | Standard charger | |
Instruction manual | A copy | |
Packaging | ABS Dedicated protective case | |
Standard Package Contents
Sync55 Night Vision Device
Sync55X Night Vision Device
Waterproof box
Data cable
Battery charger
1000mAh lithium battery
Upon unpacking and use, the standard package includes the above accessories.
