Dual-purpose low-light night vision binoculars

SSK/NW-BWHX50 series handheld starlight-level ultra-low illumination binocular night vision device, composed of a starlight-level low-illumination imaging system, a binocular correction system, and an imported OLED imaging system. This series of equipment can produce clear color or black and white images in lightless environments, effectively solving the need for 24-hour all-weather mobile day and night imaging. It supports full-color, black and white, and low-light modes selectable and switchable; and has excellent imaging capabilities, with a maximum observation distance of 1000 meters during day and night. It has been successfully applied to forest fire fighting, search and rescue, military border defense, maritime water conservancy, waterways, nature reserves, public security armed police, airports, cultural relic protection, energy mining, and other security fields such as single-soldier, single-police, and single-person patrol.

Guojin@settall.com

+86 010-63256377

Category:

Outdoor Series

Security series

Microscope series

Retail Price

¥ 9999

Market Price

¥ 9999

Model
- BWH50
- BWH50X

Leave a Message Related Solutions File Download

Quantity

Inventory Remaining

加入购物车

立即购买

隐藏域元素占位

Dual-purpose low-light night vision binoculars

Beijing Soske Technology Development Co., Ltd

Dual-purpose low-light night vision binoculars

BWH50, BWH50X

Guojin@settall.com

+86 010-63256377

Category:

Outdoor Series

Security series

Microscope series

Product Consulting Related Products File Download

Display Mode

The night vision monocular thermal imager supports 9 color modes, including white hot/black hot/brown/iron red/rainbow, etc.

Night Mode

Clearly see every detail, whether it's outdoor exploration, night observation, or late-night work. Night vision equipment provides strong support, making nightlife more practical.

Laser Rangefinder

The night vision monocular thermal imager is equipped with a high-precision, eye-safe laser rangefinding device. One-button ranging accuracy ± 1m.

Picture-in-Picture Mode

Supports continuous 1~8x picture-in-picture electronic zoom, without losing field of view, real-time observation of the image, improving target identification accuracy.

One-button Gun Calibration

Laser identification AI algorithm correction, automatically moves the reticle to the calibrated aiming point, thereby improving shooting accuracy.

Wireless Transmission

WIFI/hotspot, supports mobile APP software on mobile phones, tablets, and laptops for viewing and live streaming.

Impact Recording

High-precision real-time distance display, equipped with a high-precision, eye-safe laser rangefinding device. One-button ranging accuracy 1m.

Crosshair Reticle

The unique crosshair mode is essential for fast target acquisition and accuracy at any distance, and supports multiple color options.

Application Scenarios

Used for public security law enforcement, drug control and smuggling investigation, armed police anti-control, border patrol, coastal patrol, single-person night reconnaissance, etc.

Product Display and Accessories

Product appearance and accessories display. Accessories mainly include (main unit, waterproof box, data cable, battery charger, 26650A lithium battery, accessories).

Specifications

Binocular Multifunctional Low-Light Night Vision Binoculars
Model	SSK/NW-BWH50	SSK/NW-BWH50X
Low-Light Detector Parameters
Detector Type	1/1.8” SETTALL CMOS
Lens Focal Length	Manual fixed-focus low-light lens 50mm@(F0.9)
Resolution	1920×1080
Maximum Frame Rate	50 frames/second (1920×1080)
Color Illuminance	0.00005Lux
Black and White Illuminance	0.0000lLux@(F0.9)
Infrared Illumination	Optional sensing wavelengths: 808nm/940nm/980nm
Electronic Shutter	Auto/Manual
White Balance	Auto/Manual
Focusing Method	Manual
Electronic Zoom	1~8x continuous zoom
Zoom Mode	Zoom/Picture-in-Picture Zoom
Display Mode	Full Color Mode/Black and White Mode/Low-Light Mode
Reticle	Multiple options available
Reticle Color	Multiple options available
Detection Distance Index	For person (1.8m×0.5m)/For vehicle (2.3m×2.3m)
Detection Distance	1000m (typical climate conditions)/2500m (typical climate conditions)
Recognition Distance	280m (typical climate conditions)/600m (typical climate conditions)
Eyepiece Parameters
Display Screen	0.5-inch OLED, 1024×768 resolution
Contrast	1000:1
Eye Relief	35mm
Eyepiece Magnification	12x	15x
Image Parameters
Recording Format	MP4
Image Storage	JPG
Image Resolution	1024×768
Storage Capacity	4~64G (supports up to 256G)
Image Output	HDMI@1920×1080
Photo Playback	Supported
Video Playback	Supported
Interface Description
Data Export	USB 2.0
External Power Supply	DC 5V
Data Access		TTL can be externally connected to a wind vane/laser rangefinder
Wireless Transmission	Supports two modes: WIFI/hotspot. It supports viewing and live streaming via mobile terminal APP software (such as mobile phones, tablets, and laptops) on platforms including Facebook, Linkedin, Twitter, Douyin, and TikTok.
Data Sensor
Impact Sensor	Impact-activated recording, saving videos before and after the impact. Video length and impact sensitivity are adjustable.
One-button Gun Calibration	AI-identified laser algorithm, adjusting the dividing line to the specified position
Azimuth Sensor	Static accuracy 0.05°, dynamic 0.1°
Acceleration Sensor	2G-60G internally adjustable
Roll Angle Sensor	Range ±90°, static accuracy 0.05°, dynamic 0.1°
Pitch Angle Sensor	Range ±90°, static accuracy 0.05°, dynamic 0.1°
Laser Rangefinder
Ranging Distance		10～1500 meters, accuracy ±1m
Ranging Wavelength		Pulse 905nm
Ranging Frequency		1～20Hz adaptive
GPS/Beidou Positioning Module
Satellite Positioning		Beidou/GPS (optional), can display latitude and longitude information within 10 seconds outdoors (sensitivity -162dBm)
Target Positioning		Displays the feedback coordinates of the measured object
Physical Parameters
Waterproof and sealed	IP67 (airtight)
Operating Temperature	-40℃～+60℃
Storage Temperature	-45℃～+70℃
Operating Humidity	Humidity less than 90% (non-condensing)
Typical Power Consumption	≤2.8W
Battery Capacity	26500A rechargeable lithium battery 3.7V＠3500mAH
Working Time	Continuous working time >7 hours
Product Dimensions	220×175×75（mm）	220×175×85（mm）
Product Weight	≤1.1KG	≤1.2KG
Accessories
Composite Cable	USB Data/Charging Cable
	CVBS Video Output
Battery	Single 26500 battery @ 4200mA
Charging Plug	US/EU standard optional
Manual	One
Packaging	ABS protective case
