Monocular multi-functional low-light night vision system

The SYNL50X series monocular multifunctional low-light night vision system consists of an ultra-low-illumination imaging system and a high-resolution OLED imaging system. The product features high integration, small size, light weight, and low power consumption, making it a cost-effective product for mobile handheld fog penetration and night vision monitoring. This series of devices can produce clear color or black and white images in environments without light, effectively addressing the need for 24-hour all-weather mobile day and night imaging. It supports full-color, black and white, and low-light modes, which are selectable and switchable. It also boasts excellent imaging capabilities, with a maximum observation distance of 1000 meters during day and night. It has been successfully applied to single-soldier, single-police officer, and single-person patrol security fields such as forest fire fighting, search and rescue, military border defense, maritime and water conservancy, waterways, nature reserves, public security and armed police, airports, cultural relic protection, and energy mining.

Contact Us

Guojin@settall.com

+86 010-63256377

Category:

Outdoor Series

Security series

Microlight Scope Series

Retail Price

¥ 9999

Market Price

¥ 9999

The SYNL50X series monocular multifunctional low-light night vision system consists of an ultra-low-illumination imaging system and a high-resolution OLED imaging system. The product features high integration, small size, light weight, and low power consumption, making it a cost-effective product for mobile handheld fog penetration and night vision monitoring. This series of devices can produce clear color or black and white images in environments without light, effectively addressing the need for 24-hour all-weather mobile day and night imaging. It supports full-color, black and white, and low-light modes, which are selectable and switchable. It also boasts excellent imaging capabilities, with a maximum observation distance of 1000 meters during day and night. It has been successfully applied to single-soldier, single-police officer, and single-person patrol security fields such as forest fire fighting, search and rescue, military border defense, maritime and water conservancy, waterways, nature reserves, public security and armed police, airports, cultural relic protection, and energy mining.
  • Model
    • SYNL50
    • SYNL50X
Leave a Message Related Solutions File Download
Quantity
-
+

Inventory Remaining

198

加入购物车
立即购买

隐藏域元素占位

Monocular multi-functional low-light night vision system
Monocular multi-functional low-light night vision system
Monocular multi-functional low-light night vision system
+
  • Monocular multi-functional low-light night vision system
  • Monocular multi-functional low-light night vision system
  • Monocular multi-functional low-light night vision system
Beijing Soske Technology Development Co., Ltd

Monocular multi-functional low-light night vision system

The SYNL50X series monocular multifunctional low-light night vision system consists of an ultra-low-illumination imaging system and a high-resolution OLED imaging system. The product features high integration, small size, light weight, and low power consumption, making it a cost-effective product for mobile handheld fog penetration and night vision monitoring. This series of devices can produce clear color or black and white images in environments without light, effectively addressing the need for 24-hour all-weather mobile day and night imaging. It supports full-color, black and white, and low-light modes, which are selectable and switchable. It also boasts excellent imaging capabilities, with a maximum observation distance of 1000 meters during day and night. It has been successfully applied to single-soldier, single-police officer, and single-person patrol security fields such as forest fire fighting, search and rescue, military border defense, maritime and water conservancy, waterways, nature reserves, public security and armed police, airports, cultural relic protection, and energy mining.

SYNL50、SYNL50X

Guojin@settall.com

+86 010-63256377

Category:

Outdoor Series

Security series

Microlight Scope Series

Product Consulting Related Products File Download
Display Mode
The night vision monocular thermal imager supports 9 color modes, including white hot/black hot/brown/iron red/rainbow, etc.

Night Mode
Clearly see every detail, whether it's outdoor adventure, night observation, or late-night work. Night vision equipment provides strong support, making nightlife more practical.

Laser Rangefinder
The night vision monocular thermal imager is equipped with a high-precision, eye-safe laser rangefinding device. One-button ranging accuracy ± 1m.

Picture-in-Picture Mode
Supports continuous 1~8x picture-in-picture electronic zoom, without losing field of view, real-time observation of the image, improving target recognition accuracy.

One-button Gun Calibration
Laser identification AI algorithm correction, automatically moves the reticle to the calibrated aiming point, thereby improving shooting accuracy.

Wireless Transmission
WIFI/hotspot, supports mobile APP software on mobile phones, tablets, and laptops for viewing and live streaming.

Impact Recording
High-precision real-time distance display, equipped with a high-precision eye-safe laser rangefinding device. One-button ranging accuracy 1m.

Crosshair Reticle
The unique crosshair mode is essential for fast target acquisition and accuracy at any distance, and supports multiple color options.

Application Scenarios
Used for public security law enforcement, drug control and smuggling investigation, armed police anti-control, border patrol, coastal patrol, single-person night reconnaissance, etc.

Product Display and Accessories
Product appearance and accessories display. Accessories mainly include (main unit, waterproof box, data cable, battery charger, 26650A lithium battery, accessories).

Specifications

Monocular Multifunctional Low-Light Night Vision System

Model

SSK/NW-SYNL50

SSK/NW-SYNL50X

Low-Light Detector Parameters

Detector Type

1/1.8” Progressive Scan CMOS

Lens Focal Length

Manual fixed-focus low-light lens 50mm@(F0.9)

Resolution

1920×1080

Maximum Frame Rate

50 frames/second (1920×1080)

Color Illuminance

0.0005Lux

Black and White Illuminance

0.000lLux@ (F0.9)

Infrared Illumination

Optional sensing wavelengths 808nm/940nm/980nm

Electronic Shutter

Auto/Manual

White Balance

Auto/Manual

Focusing Method

Manual

Electronic Zoom

1～8x continuous zoom

Zoom Mode

Zoom/Picture-in-Picture Zoom

Display Mode

Full Color Mode/Black and White Mode/Low-Light Mode

Reticle

Multiple options available

Reticle Color

Multiple options available

Detection Distance Index

For person (1.8 m × 0.5 m) / For vehicle (2.3 m × 2.3 m)

Detection Distance

2500 m (typical daytime climate conditions)

Recognition Distance

600 m (typical nighttime climate conditions)

Eyepiece Parameters

Display

0.39-inch OLED, 1024×768 resolution

Contrast

1000:1

Eye Relief

35mm

Eyepiece Magnification

12x

Image Parameters

Recording Format

MP4

Image Resolution

1024×768

Storage Capacity

Standard 64G (supports up to 256G)

Image Output

HDMI@1920×1080

Photo Playback

Supported

Video Playback

Supported

Interface Description

Data Export

TAPE-C 2.0

Data Storage

CF card

External Power Supply

DC 5V, maximum current 1.5A

Wireless Transmission

Supports WIFI/hotspot modes, allowing viewing and live streaming via mobile terminal APP software on mobile phones, tablets, and laptops (platforms such as Facebook, Linkedin, Twitter, Douyin, TikTok, etc.)

Data Sensor

Ranging Distance



10-1200 meters

Ranging Wavelength



Pulse 905nm

Impact Sensor

Impact starts recording, saving video before and after the impact. Video duration and impact sensitivity are adjustable.

One-button Gun Calibration

AI-identified laser algorithm, adjusting the dividing line to the specified position

Azimuth Sensor

Static accuracy 0.05°, dynamic 0.1°

Acceleration Sensor

2G-60G internally adjustable

Roll Angle Sensor

Range ±90°, static accuracy 0.05°, dynamic 0.1°

Pitch Angle Sensor

Range ±90°, static accuracy 0.05°, dynamic 0.1°

Physical Parameters

Impact Resistance

1000G

Waterproof Sealing

IP66 (Airtight)

Operating Temperature

-40℃～+ 60℃

Storage Temperature

-45℃～+ 70℃

Operating Humidity

Humidity less than 90% (non-condensing)

Operating Voltage Range

DC2.6～5.5V

Typical Power Consumption

≤2.8W

Reverse Polarity Protection

Yes

Battery Capacity

16340 rechargeable lithium battery 3.7V＠2000mA

Product Dimensions

235×85×85（mm）

235×85×85（mm）

Product Weight

≤1.1KG

≤1.1KG

Included Accessories

Data charging cable

Type-C

Battery

16340×2@2000mA

Charger

Standard charger

Instruction Manual

One

Packaging

ABS protective case

Online Inquiry

Note: Please leave your contact information, our professionals will contact you as soon as possible!

Solutions

Content update in progress,...

Accessories

Host Device

Host device

Waterproof box

Waterproof box

Data cable

Data cable

Battery charger

Battery charger

1000A lithium battery

1000A lithium battery

Other accessories

Other accessories
